| Description | CCS-G-15K | CCS-G-15K-ZD |
| Input Voltage | 3 phase, 380V/415V | 3 phase, 380V/415V |
| Output Voltage | DC 175∼185V | DC 175∼185V |
| Initial Current | 25∼30A | 54∼60A |
| Thermal Balance Current | 25A | 44A |
| Thermal Balance Temperature | 55°C | 65°C |
| Total Power | 5Kw | 8Kw |
| Intensity of Magnetic Field | ≥15000 GS | ≥15000 GS |
| Cooling System | Outer coolant-water, inner coolant-transformer oil | Outer coolant-water, inner coolant-transformer oil |
| Demagnetizing System | Demagnetizing coil | Demagnetizing coil |
| Capacity | 5-6 mt/hr (feldspar powder) | 20∼25 mt/hr (slurry) 15∼20 mt/hr (pigment) |
| Net Weight | 800kg | 780kg |
